I’m a fan of using a half-wave antenna on a 2m handheld transceiver (HT). These come in a variety of forms but I’ve tended to use the telescoping half-waves that mount on the HT. These include the Halfwave 2 Meter Flex antenna from Smiley and the MFJ-1714 from MJF. One of the disadvantages of these two antennas is that they are designed for 2m operation only. Put it on a dualband HT and you can only use one of the bands.
Now there is a dualband alternative.
During a discussion of various VHF radios and antennas on the SOTA reflector, Phil/G4OBK recommended this antenna: TWAYRDIO RH 770 SMA-Male Dual Band Telescopic Handheld Antenna. I was mildly skeptical in that the antenna looks like cheap lowcost economy stuff from China. However, for $16.55 (free shipping), it seemed like something I should try out.
I’ve since used this antenna on several SOTA activations and have found it to work quite well. Not having to worry about whether I’m operating on 2m or 70 cm is a big plus. I liked the antenna so much, I now have three.
Recently, I wondered how well the antenna is really performing so I did a side-by-side comparison with the Smiley 2m halfwave. Now this kind of comparison is always a bit dicey unless you have a calibrated antenna range but simple comparisons are useful. I got on 2m fm with another ham running a home station some distance away such that I was not pegging his S-meter. We did several A/B comparisons between the Smiley and the RH 770. Much to my surprise, the RH 770 performed significantly better than the Smiley. That is, the other ham saw his meter deflect higher with the RH 770. I can’t give that to you in dB but I can say it’s a little better. I actually thought that the single-band design might win out due to less complexity in the antenna but the opposite was true. Your mileage may vary. No warranty expressed or implied.
The only thing I don’t like about the RH 770 is that the telescoping sections slide up and down really easy. Too easy for my taste. I’d rather have some stickiness to it so that I am sure it will remain fully extended. But I admit this is more of a personal impression than actual problem.
The antenna is available with a male SMA connector, a female SMA connector or a BNC. That should pretty much cover it.
So thanks Phil/G4OBK for pointing out this antenna. I also highly recommend it.
73, Bob K0NR
This is what I use and love it. Very firm when extended.
Do a search for HYS TC-669ET
Juan,
That looks like a clever design. You could use it all of the time (retracted) and extend it when needed.
It’s only a quarter wave on 2m, so it’s not going to perform as well as a halfwave though.
Could you try to slightly crimp the female end of each telescoping segment with a pair of slip-joint pliers to create a pinch?
Wayne,
That may be worth a try. So far, the antenna has behaved…although it seems like it might retract on its own, it has not done that.
Thanks for the recommendation, Bob. Do you find it’s necessary to adjust the length of the antenna depending on the band?
No, just extend the antenna all of the way
