Which Modes Have You Operated?

Posted on by — 7 Comments ↓
Graphic courtesy of Ham Radio School

For our local 2m net, the Net Control Station asks a Question of the Night to stimulate some discussion. Recently, the question was:

Do you have any interest in CW. If yes, Do you currently operate CW or do you plan to learn? If you have no interest in CW, what other modes besides voice do you operate on or would like to?

I am not a huge CW fan, but I do use it from time to time, especially when it comes to squeezing out difficult contacts on VHF or UHF. However, this question had me thinking about the various modes I have operated, so I made a list:

SSB - quite often on HF, VHF, UHF
CW  - not nearly as often but on HF, VHF, UHF
FM/PM - lots of VHF activity here, 2m FM is the Utility Mode
AM  - a few times, just to check it out
RTTY - I used to do this often but my interest has faded
PSK31 - I used to do this often but my interest has faded
FT8 - this one has taken over my digital operating
FT4 - a faster alternative to FT8, often better to use
Q65 - I just started using this for weak-signal VHF/UHF
MSK144 - for meteor scatter, but I haven't done that for a while
AX.25 - VHF packet radio, including APRS
DMR - the most common digital mode in Colorado
D-STAR - I used D-STAR when it first came out but lost interest
C4FM - Yaesu Fusion, I've used it a few times

Each one of these modes has a story behind it…often I was just looking for something new to try. (If you find yourself getting bored with ham radio, it might be time to try a new mode.)

This list also reminds me that I need to get back to chasing grids on the 2-meter band, using CW, SSB, FT8, MSK144, and Q65. I have a new tower up that I’ve not taken full advantage of for VHF/UHF.

That’s my list of modes used, what does your list look like?

73 Bob K0NR

Universal Digital Voice

Posted on by — 9 Comments ↓
Bob/K0NR operates VHF/UHF FM from Pikes Peak for the June VHF contest.

For the June VHF contest, I operated Single-Op Portable from the summit of Pikes Peak. I combined this with Summits On The Air (SOTA) and Parks On The Air (POTA) activations. In a few hours, I made 80 QSOs on 6m, 2m, 1.25m, 70cm, and 23cm bands. It was a fun time.

Quite a few of the contacts were made on 2m FM, The Utility Mode. Even though CW, SSB and WSJT modes are more efficient (especially with weak signals), FM is still the least common denominator for modulation. Everyone has it, so there are more QSOs available with that mode.FM is the default choice for easy VHF simplex communication.

Where Be Digital?

Perhaps it was the lack of oxygen in my brain, but I started to wonder:

Why the heck, in the year 2022 are we still using an analog mode for so much of our amateur communication?

FM was invented in the 1930s, which is ancient history from a technological point of view. It has served us well, but it is long past time to move to digital. Of course, we do have many handheld and mobile radios available that support digital voice (DV) modulation. In fact, we probably have too many digital formats to choose from, all incompatible, which has fragmented the market. The three dominant digital voice modes are D-STAR (first out of the chute), DMR (a commercial standard) and Fusion (Yaesu’s C4FM offering). I think these all have their advantages and disadvantages which attract various people to support one or more of them. However, none of them is dominant and universal, like FM. It is interesting that virtually all DV radios on VHF/UHF include analog FM because it is The Utility Mode, the fallback modulation that keeps us all compatible.

Universal Digital Voice

For this post, I am primarily looking at this from a SOTA and POTA perspective, which means simplex operation and not repeaters. (However, you could extend this idea to repeaters, too.) I am also not so concerned about keyboard modes, just DV plus some basic digital telemetry that goes with it. It can’t be too complex or it will not be fast and easy to use.

I propose a universal DV mode that is implemented in all VHF/UHF transceivers (think in terms of your typical handheld or mobile transceiver for 2m and 70cm). And yes, go ahead and also implement D-STAR, DMR, Fusion, or whatever, but give us a universal digital format that just works. The key idea is to have a digital least common denominator mode that replaces FM. This mode can be the defacto standard for “meet me on simplex” and become the Next Generation Utility Mode. How cool would it be to get on top of a summit and push the DV Call button and work stations on digital many miles away? The station’s callsign should be embedded in the digital stream along with location data (lat/lon or grid locator) and some user-defined fields ( SOTA reference or other information). This format should also have really good weak-signal performance, significantly better than FM, for when the signal-to-noise ratio is low. All the technology must be open, to encourage wide adoption, with no proprietary codecs or modulation schemes.

The technology for this already exists and it would not be difficult to implement. The real challenge is the lack of industry coordination and collaboration between amateur radio manufacturers. Unfortunately, I don’t see this changing any time soon.

That’s my thought for today. What do you think?

73 Bob K0NR

Recommended Colorado Hotspot Frequencies

Posted on by — 1 Comment ↓

A big trend in ham radio activity is the use of internet-connected transceivers commonly referred to as hotspots. These devices often use one (or more) of the popular VHF/UHF digital formats (DMR, D-STAR, Fusion) but analog FM is also used. They allow a radio amateur to have a local RF connection into one of the extensive radio networks (e.g., Brandmeister).

Unfortunately, there have been situations where radio amateurs arbitrarily chose hotspot frequencies that caused interference with existing radio activity. For example, a hotspot showed up on the 70 cm SSB calling frequency, 432.100 MHz. One of the worst examples of interference was a hotspot sitting on the input frequency of a satellite transponder. Not good.

The Colorado Council of Amateur Radio Clubs (CCARC) is the VHF/UHF frequency coordination body for the state of Colorado. Included in its spectrum management role, the CCARC maintains a detailed set of band plans (called Frequency Use Plans) for the 144 MHz, 222 MHz, 420 MHz, 902 MHz and 1200 MHz bands.

The CCARC recently decided to provide some guidance on what frequencies should be used for hotspot operation. Previously, the operator of a hotspot had to scan through the Frequency Use Plan and figure out where hotspots fit in. It wasn’t very obvious, so the CCARC now recommends 10 specific frequencies on the 70 cm band for hotspot use.

These frequencies are available for simplex hotspot use. However, for each of these simplex frequencies, there is also a corresponding frequency 5 MHz lower that can be used for hotspots that operate duplex.

Unlike repeaters, hotspots are not coordinated by the CCARC. With 10 frequencies available, it should be easy to find one that doesn’t have any co-channel interference from other users. See the complete CCARC hotspot guidance here.

These guidelines won’t solve every problem but it will help people find a hotspot frequency that plays well with others. These frequencies are valid for Colorado only. Check your local VHF/UHF band plans for more information.

73 Bob K0NR

Disclosure: I contributed to these CCARC guidelines but I don’t speak for the CCARC.

The Cacophony of Digital Voice Continues (Part 2)

Posted on by — 8 Comments ↓

Digital transmissionThis post is a continuation of The Cacophony of Digital Voice Continues (Part 1), so you probably should read that one first.

All of the popular amateur digital voice (DV) systems (D-STAR, DMR and YSF) use the AMBE vocoder (voice codec) technology. This technology was developed by Digital Voice Systems, Inc. and is proprietary technology covered by various patents. The use of proprietary technology on the ham bands causes some folks to get worked up about it, especially proponents of an open source world. See my blog posting: Digital Voice at Pacificon and this presentation by Bruce Parens K6BP: AMBE Exposed. Codec2 is an alternative open voice codec developed by David Rowe, VK5DGR. David is doing some excellent work in this space, which has already produced an open codec that is being used on the ham bands. FreeDV is an umbrella term for this open codec work. Here’s a recent video of a presentation on FreeDV by VK5DGR.

It will be interesting to see if and how Codec2 gets adopted in a DV world already dominated by AMBE. After all, a new codec is another contributor to the digital cacophony. On the HF bands, it is easier to adopt a new mode if it can be implemented via a soundcard interface (which FreeDV can do). Any two hams can load up the right software and start having a QSO. The same is true for weak-signal VHF/UHF via simplex. (Note that Flexradio also supports FreeDV, showing how Software Defined Radio (SDR) has an advantage with adopting new technology.)  VHF/UHF repeaters are trickier because you must have a solution for both the infrastructure (repeaters and networks) as well as the user radios.

The vast majority of digital repeaters support just one digital format. For example, a D-STAR repeater does not usually repeat DMR or YSF transmissions. Interestingly, DMR and YSF repeaters often support analog FM via mixed mode operation for backward compatibility. It is definitely possible to support multiple digital formats in one repeater, but the question is will large numbers of repeater owners/operators choose to do that? With existing DV systems, the networking of repeaters is unique to each format which represents another barrier to interchangeability. In particular, most of the DMR infrastructure in the US is MOTOTRBO, which won’t ever support D-STAR or YSF.

In the case of a new vocoder, we can think of that as just a new format of bits being transported by the existing DV protocol. DMR, for example, does not actually specify a particular vocoder, it’s just that the manufacturers developing DMR equipment have chosen to use AMBE technology. So from a technical viewpoint, it is easy to imagine dropping in a new vocoder into the user radio and having it work with other identical radios. Of course, these radios would be incompatible with the existing installed base. Or would they? Perhaps we’d have a backwards compatibility mode that supports communication with the older radios. This is another example of putting more flexibility into the user radio to compensate for DV incompatibilities.

One objection to AMBE is the cost of the technology, especially when compared to free. When D-STAR radios first started using AMBE codec chips, the chip cost was rumored to be $25 to $50, but I don’t have a solid source on that. Now, I see that Tytera is selling a DMR handheld at around $100, including AMBE technology inside, so the codec can’t be very expensive. If a free codec starts to be a credible threat, it will put additional pricing pressure on the AMBE solution.

A potential advantage of Codec2 is superior performance at very low signal-to-noise ratio. We’ve all experienced the not-too-graceful breakup of existing DV transmissions when signals get weak. Some of the Codec2 implementations have shown significant improvement over AMBE at low signal levels.

Conclusions

Repeating a key conclusion from Part 1:

  • For the foreseeable future, we will have D-STAR, DMR and YSF technologies being used in amateur radio. I don’t see one of them dominating or any of them disappearing any time soon.

Adding in these conclusions for Part 2:

  • Codec2 will struggle to displace the proprietary AMBE vocoder, which is well-established and works. The open source folks will promote codec2 but it will take more than that to get it into widespread use. Perhaps superior performance at low signal levels will make the difference.
  • Repeater owner/operators will continue to deploy single-DV-format repeaters. This will make multiformat radios such as the DV4mobile be very attractive. In other words, we will deal with the digital cacophony by having more flexible user radios. This will come at a higher price initially but should drop over time.

Repeating this one from Part 1:

  • A wild card here is DMR. It benefits from being a commercial land mobile standard, so high quality infrastructure equipment is available (both new and used gear). And DMR is being embraced by both land mobile providers (i.e., Motorola, Hytera) and suppliers of low cost radios (i.e., Tytera, Connect Systems). This combination may prove to be very powerful.

Well, those are my thoughts on the topic. I wish the DV world was less fragmented but I don’t see that changing any time soon. What do you think is going to happen?

73, Bob KØNR

The Cacophony of Digital Voice Continues (Part 1)

Posted on by — 4 Comments ↓

Digital transmission

It wasn’t that long ago that I commented on the state of digital voice on the VHF/UHF ham bands: Digital Voice Balkanization. We have three main competing (incompatible) standards in the running: D-STAR, DMR and Yaesu System Fusion (YSF). At a high level, these three formats all do the same thing but there are significant differences in implementation (See Comparison of Amateur Radio DV by Roland Kraatz W9HPX.) All three of these are (arguably) open standards, allowing anyone to implement equipment that supports the standard. However, the reality is that D-STAR is still largely an ICOM system (with Kenwood joining the party), YSF is mostly a Yaesu system and DMR is…well, DMR is not deeply embraced by any large amateur radio equipment supplier. Instead, DMR is promoted heavily by Motorola for the commercial market via their MOTOTRBO product line. Another big factor is the availability of DMR radios from some of the low cost providers in the ham market: Connect Systems, Tytera MD-380. Baofeng has also announced a DMR radio but it has some potential shortcomings.

D-STAR has a clear head start versus the other DV standards and is well-entrenched across the US and around the world. DMR and YSF are the late comers that are quickly catching up. To put some numbers on the adoption of DV technology, I took at the digital repeater listings in the August issue of the SERA Repeater Journal. SERA is the coordinating body for Georgia, Kentucky, Mississippi, North Carolina, South Carolina, Tennessee, Virginia and West Virginia. This is a large region that includes rural and large urban areas, so perhaps it is a good proxy for the rest of the country. I just considered the listings for D-STAR, DMR and YSF repeaters, some of which are set up as mixed-mode analog and digital repeaters.

D-STAR   161    39%
DMR      136    33%
YSF      121    29%
Total:   418   100%
SERA Repeater Journal - August 2016

I was definitely surprised at how the DMR and YSF numbers are in the ballpark with D-STAR. Of course, we don’t know for sure how many of these repeaters are actually on the air or how many users are active on each one. Still, pretty impressive numbers. (And I did not bother to count the analog FM repeaters but those numbers are way higher, of course.)

It is the repeater clubs and repeater owners that drive the deployment of infrastructure for new technology. To some extent, they are driven by what their users want but also by their own technical interests and biases. One of the positive factors for DMR is that most of these systems are Motorola MOTOTRBO. Hams involved in commercial land mobile radio are exposed to that technology and naturally port it into the amateur radio world. MOTOTRBO is actually not that expensive and it’s built for commercial use. YSF received a big boost when Yaesu offered their repeater for $500 to clubs and owners that would put them on the air. By using Yaesu’s mixed analog/digital mode, it was an easy and attractive upgrade for aging repeater equipment.

Disruption From New Players

Early on in the world of D-STAR, the DV Dongle and DV Access Point by Robin AA4RC allowed hams to access the D-STAR network without needing a local repeater. This basic idea has continued and evolved in several different directions. For example, the DV4Mini is a cute little USB stick that implements a hot spot for…wait for it…D-STAR, DMR and YSF. This is very affordable technology (darn right cheap) that lets any ham develop his or her own local infrastructure. We don’t need no stinkin’ repeater. DV MEGA is another hot spot, supporting D-STAR, DMR and YSF. Oh, and then there’s openSPOT…don’t want to leave them out. I guess somebody forgot to tell these guys they have to choose one format and religiously support only that one.

dv4-mobile-transceiver
DV4 Mobile Transceiver as shown in Dayton 2016

OK, so that’s one way to solve the babel fish problem…support all three formats in one device. And that’s what the DV4 mobile radio promises to do as well: “This DV4mobile is a tri-band VHF/UHF transceiver (2m, 1.25m and 70cm) that supports DMR, D-STAR and C4FM ( or “fusion”) all in one box.” Heck, let’s throw in LTE while we are at it, it’s only software. This site says the radio will be available Q4 2016. Well, it’s Q4, so maybe it will be here soon.

Conclusions

So let’s wrap up Part 1 of this story. What can we conclude?

  • For the foreseeable future, we will have D-STAR, DMR and YSF technologies being used in amateur radio. I don’t see one of them dominating or any of them disappearing any time soon.
  • Equipment that handles all three of those DV modes will be highly desirable. It is the most obvious way to deal with the multiple formats. Software-defined radios will play a key role here.
  • A wild card here is DMR. It benefits from being a commercial land mobile standard, so high quality infrastructure equipment is available (both new and used gear). And DMR is being embraced by both land mobile providers (i.e., Motorola, Hytera) and suppliers of low cost radios (i.e., Tytera, Connect Systems). This combination may prove to be very powerful.

Digital Voice at Pacificon

Posted on by — 2 Comments ↓

Last weekend, I had the privilege of attending the Pacificon amateur radio convention in Santa Clara, something I have been trying to do for several years now. It is a great event, with good technical programs and a super venue.

The most interesting presentation I saw was the one on digital voice (DV) technology by Bruce Perens K6BP. The presentation was mostly about the digital voice known as FreeDV,  an open source approach to DV that uses the Codec 2 voice codec for digitally processing/compressing speech.

K6BP photo
Bruce Perens K6BP talking about FreeDV

I won’t cover all of the technical details here but you can follow the links above to go deeper on the topic. The initial FreeDV efforts are focused on the HF bands, using the sound card plus computer approach to implementing DV. This is a good approach since it is a relatively easy way to adopt this technology. (Compare this to VHF/UHF where you need to solve the repeater infrastructure problem to make progress.) FreeDV operates with a bandwidth of  1.25 kHz, narrower that the standard 3 kHz or so SSB signal. FreeDV also has the benefit of degrading gracefully as the  signal-to-noise ratio is decreased, with less of a digital dropoff that we see with D-STAR and other DV technologies.

Like many hams, Bruce pointed out the concerns and limitations of the proprietary AMBE chip used in D-STAR, DMR and now the new Yaesu DV system. I totally get this point and support the idea of a an open source codec. On the other hand, this work is coming more than a decade later than the creation of D-STAR. I like to refer to this phenomenon as “our ideas are better than their products.”

Bruce introduced Chris Testa KB2BMH to talk about the “HT of the Future”. This is a handheld transceiver implemented using Software Defined Radio (SDR) and inspirations from the world of smartphones. As Bruce said, “Why isn’t your HT as smart as your smart phone?” This is similar to the Android HT idea that I blogged about a while back. See Chris’s blog and this HamRadioNow video for more information.

Another presentation that I attended was about D-STAR with several speakers, including Robin AA4RC. The innovation continues to happen in the D-STAR world with a strong theme of using Raspberry Pi computers to create D-STAR hotspots and repeaters. Robin described the “DV Pi” being developed…a DVAP-like daughter board that plugs into a Raspberry Pi. Jim Moen K6JM talked about the many ways you can implement a D-STAR Hotspot. For more info on that see his D-STAR Hotspot page.

There’s much innovation happening in the area of Digital Voice. It got me thinking about it again so I dug out my ICOM D-STAR HT and put my DVAP back on the air.

73, Bob K0NR

The Android HT

Posted on by

I’ve been watching all of the innovative work going on in the smartphone and tablet arena and wondering how we could get more of that going in ham radio. To be sure, there are always radio amateurs developing creative technology. Some examples are adaptations of D-STAR, IRLP, improvements on APRS and sound card modulation modes. However, amateur radio is missing a standardized platform for handheld communications. Such a radio platform could open up lots of software innovation in this space.

What I have in mind is a dualband (2M/70cm) handheld transceiver that is built on top of the Android operating system. (Sorry Apple Fan Boys, iOS is a non-starter based on Apple’s walled garden philosophy.) This radio would have some of the hardware features we now take for granted in smartphones: GPS, WiFi, USB, maybe even a camera. I’d also include APRS hardware built-in, similar to the Yaesu VX-8GR or the Kenwood TH-D72A. I’ve hacked together a concept photo shown on the left of this post (click to enlarge). We would probably want to maintain some of the most important direct hardware controls such as PTT, volume and channel select. The rest of the user interface would be done via a touchscreen display, where the power of the Android OS comes into play.

While this hardware configuration is exciting, the real power comes from having a software developers kit (SDK) with a stable Application Programming Interface (API). This would unleash the creativity of all those software-oriented hams out there and a plethora of apps would emerge. There are plenty of ham radio apps available on the Apple and Android platforms…it’s just they are missing the radio as part of the package. An obvious area for innovation would initially be in APRS or maybe D-STAR. We could actually have the equivalent of SMS text messaging on ham radio, backed up via the WiFi connection. (Yeah, this kind of exists already but it is really cumbersome to use due to the braindead menu-driven user interfaces of current radios.) Just think how easy programming the radio would be with a touchscreen approach.

This is the type of product development that requires significant investment, but the technology is readily available. I suppose a garage shop operation could get this done but one of the big radio manufacturers could easily pull this off. Maybe one of those upstarts from China might want to take this on. Whoever does it, just send me $5 per unit and I’ll be happy :-).

That’s my best idea for this morning. What do you think?

73, Bob K0NR

New Transceiver from ICOM: IC-7100

Posted on by

ICOM has shown the new IC-7100 at the JARL show in Tokyo. The interwebz is buzzing with information, including a preliminary data sheet.

My scan of the preliminary datasheet indicates that this radio is in the class of the IC-7000 or even the IC-706. It covers all modes on HF plus 6 Meters, 2 Meters and 70 cm. (It also has the 70 MHz band which is a nice add for the European countries that have that band.) The radio includes DV (D-STAR) modulation capability and has a new touchscreen user interface. The slanted control panel is meant to make the touchscreen more accessible.

A new HF plus VHF/UHF radio always gets my attention (see my plea for an FT-950 with 2 Meters).  I am starting to think that the real benefit of this rig is the addition of D-STAR capability, which would a good but not essential feature to have.

What do you think?

73, Bob K0NR

Update (30 Aug 2012): Universal Radio has the radio on its website.
There’s a good video look at the radio here.

A New Digital VHF/UHF Radio from Yaesu

Posted on by
A while back, Yaesu published a white paper/brochure on VHF/UHF digital technology that slammed D-STAR for using GMSK modulation and stated that C4FM (4-Level FSK) is the way to go. See my previous posting on that topic. The paper also talked about DMR and APCO 25 as standards that use C4FM.
Page 14 of the document says:
At this point in time Vertex Standard believes the C4FM (4-level FSK) FDMA or TDMA are the most suitable selections for Amateur radio applications. In early 2012, we will release a C4FM (4-level FSK) FDMA Handy-Talky and a Mobile transceiver into the Amateur radio market. After our initial introduction, we plan to introduce a C4FM (4-level FSK) TDMA (2 slots) or TDMA Handy and Mobile transceiver into the Amateur market.
This led to speculation that we would see a Yaesu DMR or APCO 25 radio at the Dayton Hamvention. The topic was hotly debated in various online forums, with the prevailing theory being that it would be a DMR radio to play and compete with Motorola’s MOTOTRBO™ radios. It now seems that the initial introduction is the FT-1D, a dualband handheld that just does analog FM and a plain C4FM digital format (no DMR or APCO 25 protocol).  This blog has the product brochure for the FT-1D.  (Click on “Page 1” and “Page 2” links.)
The general reaction from the ham radio community is WTF, over? I don’t know why anyone would buy a radio to use with digital C4FM modulation. This digital mode is incompatible with D-STAR, DMR and APCO 25…the most common digital formats on the VHF/UHF ham bands. The quote listed above indicates that there will be more coming from Yaesu later in the year, that includes TDMA. This could be DMR but who knows?
– 73, Bob K0NR

Mixed Signals from Yaesu

Posted on by

This just in from the Things That Make You Go Hmmm Department: the amateur radio portion of Yaesu splits from Mother Motorola while the land mobile portion stays. This is right on top of an announcement that Yaesu will pursue a digital amateur radio offering based on land mobile technology (i.e., definitely not D-STAR).

The K0KDS blog has a post about the split, so go there for the full story. The ARRL has this news item about the organizational change. Here’s the paper that Yaesu published about their move into digital technology for amateur radio.

73, Bob K0NR

Completing the 2010 Trip Around the Sun

Posted on by

As the year 2010 comes to an end, I feel compelled to write something really insightful and meaningful as we log another trip around the sun. Perhaps some brilliant insights for the coming year? Or predictions of future technology breakthroughs?

Instead, I am writing this.

This is a mishmash of my thoughts about amateur radio at the start of 2011:

  • Tech License Class: One of the most fun and rewarding ham radio things I did this year was help teach a couple of Technician License Classes. There is nothing like engaging with newbies to the hobby to give you a new perspective on how cool amateur radio really is! I have a great set of teammates that made this class fun and successful: Stu W0STU, Paul AA0K and Joyce K0JJW.
  • Next Challenge: The challenge we see right now is helping these newly licensed Techs get engaged with amateur radio, so they don’t drop out. My belief is that the Technician License is a beginners permit that only enables a person to get started in the hobby. We are cooking up some fun activities to keep them going.
  • Public Service: We have a good thing going with the local fire district and the RACES group in our county in terms of real engagement on emergency communications. This is fun, rewarding and a good thing for our local community.
  • Dayton Hamvention: I am going to skip Dayton (again) this year. Instead, I’ll attend the International Wireless Communications Expo (IWCE), a trade show centered on land mobile and mobile wireless communications. For me, it has an interesting mix of emergency communications, land mobile, data/voice convergence and test & measurement topics. Oh, did I mention that it is in Las Vegas?  I suspect that it will be a better venue than Hara Arena 🙂
  • ICOM IC-9100: I have been patiently waiting for this rig to move from vaporware status to reality. Maybe it will happen this year?
  • Keep On Writing: I find that writing is good therapy, so I will keep that on the list for 2011. Mostly it will be this blog and the FM column for CQ VHF magazine.
  • Operating: It seems I don’t actually get on the air as often as I’d like, certainly not for the casual ragchewing QSO. Operating events seem to be a good way for me to get some air time: VHF Contests, Colorado 14er event, Colorado QSO Party, maybe an HF contest or two.
  • D-STAR: I haven’t been spending much time with D-STAR lately and I want to increase the focus on it. D-STAR falls into that dorking around with new technology category where experimenting with it and learning about it is the main activity.  The technology continues to grow in adoption…arguably slow in real terms as the analog modes have such a huge installed base.
  • APRS: Oddly enough, I have been messing around with APRS again, mostly thinking of it as a tracking tool for hiking and other outdoor activities. Maybe we need to look at bridging APRS with D-STAR location data?

Amateur radio is clearly my #1 hobby interest, and by a wide margin. But it is primarily a hobby (yes, with a public service hook to it…at least for me). It is important to keep it in perspective and not let it turn into another job. I already have one of those.

What are you going to be doing in 2011?

73, Bob K0NR
